Product Overview
Two-Bolt Medium Duty Ball Bearing Pillow Block for 1-15/16 Inch Shafts, 211 Series Insert
Condition
Unused new old stock. One pillow block bearing unit. Markings legible: P/N 128480 and R0320/0670 on the AIR HANDLING label; DODGE D-LOK and 211 on the collar; DLM 1-15/16, DODGE and 211 on the insert.
Ready to ship from our Idaho warehouse the same or next business day. Selling online since 1999.
Product Overview
A two-bolt pillow block carries a 1-15/16 inch shaft in a 211 series ball bearing insert, locked by a clamp collar. The P2B-DLMAH-115 is a medium duty, non-expansion unit, so it holds the shaft in place axially instead of letting it float.
Key Features
- 1-15/16 inch bore, 211 series ball bearing insert
- Two-bolt base with slotted mounting holes
- Bolt center-to-center 6.38 to 7.44 inches
- 2-1/2 inch base to bore centerline
- 8.88 inches overall length by 4.96 inches overall height
- Clamp collar locking, marked DODGE D-LOK
- Single lip contact seal
- Non-expansion (fixed) bearing
- Grease fitting on the housing; relubricatable
- Cast iron housing with a steel insert
- Maximum speed 3500 rpm; dynamic load capacity 9755 lbf, static 6588 lbf
Applications
- Replacing a worn 1-15/16 inch two-bolt pillow block on an existing shaft line
- Holding the fixed end of a shaft that carries an expansion bearing at its other end
- Stocking a spare for a P2B-DLMAH-115 already on a parts list
Frequently Asked Questions
Can it be regreased?
Yes. It has a grease fitting on top of the housing and is relubricatable.
Is this an expansion bearing?
No. It is a non-expansion unit, which fixes the shaft's axial position.
Will it drop in for a P2B-DLMAH-115 already on my machine?
Yes. Part number 128480 is the catalog number for the P2B-DLMAH-115, and the insert is a DLM 1-15/16, 211 series. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
DLM 1-15/16. 211. AIR HANDLING. Set it beside the worn unit on your shaft and let the numbers decide.
