Product Overview
Unused Cognex DMR-260X-1120 DataMan Barcode Scanner with CCB-PWRIO-05 and CCB-84901-2001-05 Cables
The Cognex DMR-260X-1120 is a fixed-mount DataMan 260 series barcode scanner designed for high-speed, industrial-grade decoding of both 1D and 2D symbols. Engineered for demanding environments, it uses Cognex’s advanced image processing and decoding algorithms to read low-contrast, damaged, and direct part mark codes reliably on fast-moving production lines.
This unused new old stock unit includes two OEM cables: a CCB-PWRIO-05 power and I/O cable and a CCB-84901-2001-05 X-coded M12 8-pin to RJ-45 Ethernet cable, both approximately 5 meters in length.
Product Condition
Unused, new old stock. Clean, uninstalled scanner with two OEM 5-meter connector cables. Packaging may show minor storage wear.
Product Overview
Cognex DataMan scanners are widely used in automated inspection, traceability, and part-verification systems. The DMR-260X-1120 employs a global-shutter image sensor and decoding engines such as 1DMax, 2DMax, PowerGrid, and Hotbars to handle difficult barcodes and direct part marks on metals and plastics. With configurable optics, modular lighting, and support for Ethernet and RS-232, it integrates seamlessly into PLC-driven automation networks.
Key Features
- Model DMR-260X-1120 – Cognex DataMan 260 series scanner
- Includes CCB-PWRIO-05 power and I/O cable
- Includes CCB-84901-2001-05 5-meter X-coded M12 8-pin to RJ-45 Ethernet cable
- Global-shutter image sensor (typical 752 × 480 px)
- Advanced decoding: 1DMax, 2DMax, PowerGrid, Hotbars
- Reads low-contrast, damaged, or DPM codes
- Omnidirectional 1D/2D capture, multi-code decoding
- Up to 45 decodes per second for high-speed lines
- Configurable high-power LED lighting modules
- Supports liquid lens or manual-focus options
- Working distances typically from 40 mm to 1 meter
- IP65-rated housing for industrial dust and water protection
- Ethernet and RS-232 connectivity with TCP/IP, EtherNet/IP, and PROFINET support
- Straight or right-angle form factors for flexible mounting
Applications
- Automated part tracking and traceability
- Quality inspection and production verification
- Warehouse and logistics barcode capture
- DPM reading on machined or coated parts
- Inventory and WIP control systems
- Automated packaging, assembly, and test lines
- OEM integration for advanced barcode solutions
Frequently Asked Questions
What codes can the DMR-260X-1120 read?
It reads both 1D and 2D barcodes, including challenging low-contrast and DPM marks using Cognex’s advanced decoding algorithms.
Does the listing include OEM cables?
Yes. It includes both a CCB-PWRIO-05 power/I/O cable and a CCB-84901-2001-05 X-coded M12 8-pin to RJ-45 Ethernet cable.
Is the scanner suited for harsh environments?
Yes. The IP65-rated enclosure protects against dust and water ingress for typical industrial settings.
How does the scanner connect to automation systems?
Supporting Ethernet and RS-232, with standard industrial protocols such as TCP/IP, EtherNet/IP, and PROFINET.
Is this a good choice for DPM applications?
Yes. Its sensor and decoding suite are optimized for reading direct part marks on metals, plastics, and other difficult surfaces.
The DataMan 260 series is built for speed, where milliseconds matter, and for marks that leave little margin. This preserved unit is ready to anchor the next production cell or inspection station with the precision Cognex is known for.
