Product Overview
Omnidirectional Spring Wand Reverse Safety Actuator with Brackets
Condition
Unused new old stock (NOS). Complete kit includes the switch body with flexible spring wand actuator, two slotted mounting brackets, threaded cord grip gland, squeeze conduit fitting, and fastener hardware. Components show clean surfaces with no signs of prior mounting or installation wear.
Same or next business day shipping from our Idaho warehouse. Reliable parts since 1999. Honest pricing, no nonsense.
We are here for our customers, with a no-hassle satisfaction guarantee.
Product Overview
Preco SWM43C is an omnidirectional mechanical limit switch kit designed for reverse alarm and safety signaling circuits on mobile equipment, forklifts, and industrial machinery. The flexible coil-spring actuator provides 360-degree deflection to trigger alarm circuits regardless of the angle of mechanical contact. Built with a rugged composite housing and sealed wire entries, it accommodates internal wiring configurations for either normally open or normally closed operation.
Key Features
- 360-degree omnidirectional coil-spring wand actuator with protective rubber boot
- Field-configurable internal snap-action switch with screw terminals for Common, Normally Open (NO), and Normally Closed (NC)
- Electrical contact rating of 5 A at 12 VDC, compatible with 12 VDC to 80 VDC vehicle circuits
- Weather-resistant molded composite housing with gasketed rear access plate
- Dual slotted steel mounting brackets for multi-axis position adjustment
- Includes threaded liquid-tight cord grip and metallic conduit clamp fitting
- Complete installation fastener set including long pan-head machine screws, flat washers, star lock washers, and hex nuts
Applications
- Replacing worn reverse alarm trigger switches on warehouse forklifts during scheduled maintenance
- Installing mechanical position sensing on heavy machinery shift linkages or tailgates
- Adding reverse-indicator or travel-warning switches to custom utility trailers, yard trucks, or service vehicles
- Rigging mechanical trip-wire or perimeter limit switches for workshop safety gates and automated shop doors
- Constructing physical limit triggers on maker CNC gantries, robotics platforms, or material-handling cart stops
Frequently Asked Questions
How is the switch wired for normally open versus normally closed circuits?
The internal snap-action microswitch features individual screw terminals for Common (C), Normally Open (NO), and Normally Closed (NC). Removing the rear housing cover allows direct terminal access to wire the switch according to your vehicle's alarm control circuit.
What direction can the actuator wand be deflected?
The coil-spring wand deflects 360 degrees in any direction from center. When mechanical contact releases, internal spring tension returns the wand to its resting center position.
What part numbers or earlier models does the SWM43C replace?
The SWM43C directly succeeds the legacy Preco SWM-43 switch and crosses to Truck-Lite TK92907, Grote 44421, and ECCO SW30 reverse alarm switches. Quantity pricing applies: the price-break table on this page shows the price per piece at every step.
A good reverse switch does not care whether a lever bumped it from the top, side, or an awkward angle - the spring gives, the contacts snap, and the alarm sounds before metal meets metal. Bolt on the brackets, terminate your pair, and keep the yard rolling safely.
