Product Overview
Single-Phase 3 kVA Step-Down Transformer with 140, 160 and 180 Volt Secondary Taps
Condition
Used, in good physical condition with surface marks from prior use and storage; structurally sound and complete, with terminals and housing intact and no visible damage or corrosion. The windings were checked for continuity and the unit was inspected visually; no further electrical testing was performed. Markings legible: POWERTRAN FERNDALE, MI U.S.A., CAT NO: MHI-3K-208/160, 3 KVA 1 PHASE, INPUT VOLTAGE 208V H1-H2, OUTPUT VOLTAGE 140V X1-X2, 160V X1-X3 OR 180V X1-X4, MAXIMUM SECONDARY AMPS 15A, HZ: 60, INSUL: F, RISE: 115, CODE: 0809, and a UL recognized component mark with FILE NO. E105557, TRANSFORMER INSULATION SYSTEM DESIGNATED-PT-180-E.
Ships same or next business day from our Idaho warehouse. Selling online since 1999.
Product Overview
A single-phase Powertran isolation transformer that takes 208 volts and delivers 140, 160 or 180 volts, chosen by which X lead pair is wired.
Key Features
- 3 kVA, single phase, 60 Hz
- Input 208 V on leads H1-H2
- Output 140 V on X1-X2, 160 V on X1-X3, 180 V on X1-X4
- Maximum secondary current 15 A
- INSUL: F, RISE: 115
- Steel enclosure
- Flying leads in an open wiring end, with slotted mounting feet
Applications
- Supplying equipment that calls for 140, 160 or 180 volts from a 208 volt single-phase line
- Replacing a failed MHI-3K-208/160 in an existing panel or machine
Frequently Asked Questions
Which leads give 160 volts?
X1 and X3. 140 V comes off X1-X2 and 180 V off X1-X4, with the 208 V input on H1-H2.
What input voltage does it take?
208 volts, 60 Hz, single phase, on H1-H2.
How much current can the secondary carry?
15 amps maximum.
Has it been tested under load?
No. The windings were checked for continuity and the unit was inspected visually; no powered or load test was done. You get the transformer with its leads as they are, and a powered check on your bench is yours. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
Three secondary taps, 140, 160 and 180, which is an unusual menu for a 208 volt line. The windings answered a continuity check, and the voltages are yours to confirm.
