Product Overview
Bearing Scope Unit with Front CRT Controls and +11 to +16 Volts DC Power, Offered Without Antenna or Cables
Condition
One used unit, sold AS-IS for parts, refurbishment or experimental use, and offered without antenna or cables. Visual inspection only. Function testing not performed. Markings legible: OAR, DF4003A, Model 4003A, Serial No. 214, DANGER THIS UNIT CONTAINS LETHAL VOLTAGES DO NOT OPEN, +11 TO +16 VOLTS DC, 1 AMP, an APACHE 62810 stamp, and a red tag with NVG EQUIPMENT MODIFIED BY APACHE 62810 MIL-L-85762.
Selling online since 1999. This one ships from our Idaho warehouse the same or next business day.
Product Overview
Built around a hooded round scope with a numbered bearing scale, the DF4003A is a Doppler radio direction finder from OAR. Gain, range and audio knobs sit beside the scope, and a rear panel of switches and connectors handles antenna, receiver and power hookup.
Key Features
- Scope controls marked VERT POS, HORZ POS, FOCUS and CRT OFF / INTEN
- CRT GAIN, ANT RANGE and AUDIO LEVEL / PWR OFF knobs
- CRT RESPONSE NORM / SLOW, TRACK & HOLD OFF / ON and SPEAKER AUDIO / TONES switches
- BEARING and HOLDING marked on either side of one indicator lens
- Front PHONES jack
- Rear DISPLAY NORM / REV, RECEPTION FM / AM and ANTENNA UP / DOWN switches
- Rear CRT PHASE A / B selector, PHASING dial and INPUT SIGNAL IF / AUDIO switch
- Rear connections marked ANT CONT, PWR IN, PWR OUT, RECORDER, RCVR DEMOD, RCVR AUDIO and IF INPUT
- Power input +11 to +16 volts DC, 1 amp fuse
- Hood over the scope and two rear handle bars
- Aluminum chassis
Applications
- Pulling the scope, knobs or switches to repair another DF4003A
- Restoring a DF4003A for a vintage direction-finding collection, with an antenna and cables sourced separately
- Bench study of an older DF display and its phasing controls in a radio lab
Frequently Asked Questions
What power does it take?
+11 to +16 volts DC, through a 1 amp fuse at the rear.
Does it have an IF input?
Yes. The rear carries an IF INPUT jack, and the INPUT SIGNAL switch has IF and AUDIO positions.
Does it come with an antenna or cables?
No. It is offered without antenna or cables, and it has not been tested because the antenna and cables are missing; you get the unit itself, for parts, refurbishment or experimental use. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
The scope hood, the CRT GAIN knob and an APACHE 62810 stamp all made the trip. The antenna and its cables did not.
