Product Overview
U.S. Standard Series Sieve No. 5 With 4000 Micron, 0.157 Inch Openings for Particle Size Grading
Condition
Unused, clean and in very good condition, with some minor cosmetic blemishes. Label legible: U. S. STANDARD SIEVE SERIES, SIEVE NO. 5, A.S.T.M. E-11 SPECIFICATIONS, MICRONS 4000, OPENING 0.157 IN, OPENING 4.00 MM, DUAL MANUFACTURING CO., CHICAGO, ILL. 60618 U.S.A.
Ready to ship from our Idaho warehouse the same or next business day. Selling online since 1999.
Product Overview
Sieve No. 5 in the U.S. Standard series passes particles smaller than a 4.00 mm opening and holds back the larger ones. The label carries the ASTM E-11 specification and gives the opening in microns, inches and millimeters. A gold-tone frame with a rolled rim holds bright square-weave wire cloth across the bottom. The pictured sieve is representative.
Key Features
- Sieve No. 5, 4000 microns
- Opening 0.157 inch, 4.00 mm
- A.S.T.M. E-11 specifications on the label
- Square-weave wire cloth
- Brass frame with stainless steel wire mesh
- 2 inch depth to the wire mesh
- Gold-tone frame with rolled rim and a stepped lower band
- Dual Manufacturing Co., Chicago, Ill. label
Applications
- Splitting off the coarse fraction in a gradation stack for aggregate or soil testing
- Replacing a damaged No. 5 in an existing sieve set
Frequently Asked Questions
Is a lid or pan included?
Not included.
Can I check the opening size with calipers?
Yes. A clear square between wires on this cloth should read 4.00 mm, 0.157 inch, the two figures on the label. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
The label gives the opening three ways, in microns, inches and millimeters, so nobody at the bench has to convert. Pick the unit your test method uses and read it straight off the plate.
