Teledyne Hastings CVH-3 Vacuum Gauge MR-14-05, DV-23 Tube, 5 x 4 In, Used

Teledyne Hastings

$82.99
SKU:
000072223042CC23LS
Condition:
Used
Availability:
Usually ships same or next business day.
Adding to cart… The item has been added

Product Overview

Millitorr Panel Vacuum Gauge with Knob, Rear Cylinder and Cabled Connector

Condition

Used, in good condition, removed from a Gatan ion mill, and sold as one gauge with its attached cables. Visual inspection only. Function testing not performed. Markings legible: VACUUM GAUGE, millitorr, 0, 20, 50, 100, 200, 500, 1T, 2T, 5T, ATM, Manufactured under one or more U.S. Patents No. 3,260,113 and Patent Pending, and Uses Type DV-23 Gauge Tube on the face; MODEL NO. MR-14-05, SPEC. 917626, 01 33 0 and 502252 on the rear label; 031346 on a rear sticker; CVH-3, SERIAL 4219, U.S. PAT. NOS. 3147618, 3181357, 3204462, 3229522, 3260113, 3443434, 3613448, 3785206, 3912897, 4016759, 4041757, AND PATENTS PENDING on the cylinder label; CONTROL, POWER and GAUGE at the cylinder's cable end.

Ships from our Idaho warehouse the same or next business day. We've been selling online since 1999.

Product Overview

A Teledyne Hastings CVH-3 millitorr vacuum gauge, with MODEL NO. MR-14-05 on the rear label, a 5 inch x 4 inch gauge face and the gray CVH-3 cylinder behind the meter. It uses a Type DV-23 gauge tube.

Key Features

  • 5 inch x 4 inch gauge face
  • Millitorr scale from 0 to 500, then 1T, 2T, 5T and ATM
  • Uses a Type DV-23 gauge tube
  • Front knob with a red ring
  • Gray CVH-3 cylinder, serial 4219, behind the meter
  • Round 8-socket connector on one gray cable
  • Gray cable ending in loose red and black leads
  • Two studs on the rear panel

Frequently Asked Questions

What gauge tube does it use?

A Type DV-23 gauge tube.

How big is the gauge face?

5 inch x 4 inch.

Has it been tested?

No. Visual inspection only; function testing was not performed. It is used, in good condition, removed from a Gatan ion mill, with its cables attached. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

The scale climbs from 0 through 500 millitorr, then crowds 1T, 2T and 5T in just before ATM. Atmosphere gets the last word on this one.
