MKS 1002345400 45 Degree Buttweld Elbow Fitting, 4.0 in OD, 304 SS, Unused

MKS

$40.96
SKU:
000011423018B23StoreMulti
Condition:
New
Availability:
Usually ships same or next business day.
Bulk Pricing:
Buy in bulk and save
Adding to cart… The item has been added

Product Overview

45 Degree Butt Weld Elbow for 4.0 Inch OD Vacuum Tube, 0.083 Inch Wall, Series 23

Condition

Unused new old stock in sealed manufacturer's packaging, sold as one elbow. The unit pictured is representative of stock. Markings legible on the pictured unit's packaging: 1002345400, ELBOW BW 45DEG 4.0"OD, QTY 1.

Selling online since 1999. It ships from our Idaho warehouse the same or next business day.

Product Overview

A 45 degree butt weld elbow for 4.0 inch OD tube, in 304 stainless steel with a 0.083 inch wall. It belongs to the MKS Series 23 butt weld vacuum fittings, with a 6 inch elbow radius and a 2.49 inch A dimension.

Key Features

  • 45 degree bend with butt weld ends
  • 4.0 inch tube OD
  • 0.083 inch wall
  • 304 stainless steel
  • 6 inch elbow radius
  • Dimension A: 2.49 inch
  • Series 23 butt weld vacuum fitting

Applications

  • Turning a welded 4.0 inch OD vacuum line through 45 degrees
  • Replacing a damaged 45 degree section in an existing 4.0 inch OD stainless run
  • Stocking a matched Series 23 elbow for planned vacuum system work

Frequently Asked Questions

What wall thickness does it have?

0.083 inch, on a 4.0 inch tube OD.

What is the bend radius?

6 inches, with a dimension A of 2.49 inches.

Is it 304 stainless steel?

Yes. It is 304 stainless steel, unused NOS in sealed manufacturer's packaging. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

A 6 inch radius on a 4.0 inch tube makes an easy lean, not a sharp corner. Mark where your line needs to change direction and hold this against it.
