Product Overview
DIN Mount TC Signal Converter with 20-30 VDC Supply, 0-(5)10V Output and Zero and Span Adjustment
Condition
Used and sold each; it appears in nice condition. Visual inspection only. Function testing not performed. The unit pictured is representative of stock, with these markings legible: OMEGA, TC CONVERTER, NR. 2813253, MCR-TC/U-E/NC-O, CE, POWER 20-30VDC, 80mA, ZERO SPAN ±5% ±5%, TEMPERATURE -20 ... +65°C -4 ... +145°F, APPROVALS, SERIAL NUMBER.
Ships from our Idaho warehouse the same or next business day. We've been selling online since 1999.
Product Overview
Omega's 2813253, also numbered MCR-TC/U-E/NC-O, is a TC converter in a green DIN mount housing with vented sides. It takes its input on terminals 6 and 7 and gives a 0-(5)10V output on terminals 3 and 4, with 20-30 VDC power on terminals 1 and 2.
Key Features
- Supply: 20-30 VDC, 80 mA
- Output: 0-(5)10V
- Zero and span: ±5% each
- Temperature: -20 to +65 °C (-4 to +145 °F)
- Terminals 1 to 8: power on 1 and 2, output on 3 and 4, MM on 5, input (-) on 6 and (+) on 7, shield on 8
- Front: green and red indicators and three round black buttons, with POWER, ZERO MODE, SPAN and MODE printed beside them
- Green DIN mount housing with vented sides
Applications
- Keeping a spare for a control panel that already runs a 2813253 converter
- Bench work on a TC signal chain, wiring input, output and supply to numbered screw terminals
- Training panels where technicians practice DIN mount wiring and zero and span setup
Frequently Asked Questions
What supply voltage does it need?
20-30 VDC, at 80 mA.
What output does it give?
0-(5)10V, on terminals 3 and 4.
Can zero and span be adjusted?
Yes. Each has a ±5% range.
Has this converter been tested?
No. It appears in nice condition and has had a visual inspection only, with no function testing, so proving it in service is yours to take on. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
Eight numbered terminals and a block diagram leave little guesswork about where each wire lands. What it does on your bench is the next thing to learn.
