Teledyne Hastings Model 400 - 4-Channel Power Supply for Mass Flow Meters, Controllers, and Pressure Instruments
Condition
Single unit available. Used, sourced from a government research facility. Unit shows light surface scratches on the front panel, minor scuffs on the brushed aluminum rear and side panels, chipped black finish at the lower-left front corner, and a peeling label edge. The chrome carry handle and desktop stand are intact. Confirmed to power on. All four channel knobs, OPEN/AUTO/CLOSED switches, and the Power/Channel Select knob are responsive. The LCD display is active and clear. Rear panel carries four D-sub connectors (Channels 1-4), a labeled terminal block for external command inputs, and an F1 0.5A fuse holder. Power cord with intact plug is attached. Full functional testing with connected instruments was not performed. Photos show the specific unit you will receive.
Carefully packed and shipped same business day from our Idaho warehouse. Online since 1999. Honest equipment and straightforward service.
No hassle resolution if there is an issue. Serving customers since 1999.
Product Overview
Teledyne Hastings Model 400 is a bench-top or half-rack panel-mountable power supply and readout unit designed to operate up to four Teledyne Hastings instruments simultaneously. Confirmed by the rear panel label: Model 400, Serial No. 267, manufactured in Hampton, VA. It supplies regulated DC power and supports 4-20 mA analog signal compatibility for mass flow meters, mass flow controllers, vacuum gauges, and pressure transducers. Input accepts 100-125 VAC or 200-250 VAC at 50/60 Hz, making it usable on both North American and international power standards. The internal identifier 247C appears on documentation associated with this unit and may represent a sub-component or configuration code - not confirmed as a standalone model number.
Key Features
- 4 independent instrument channels - powers up to four Teledyne Hastings flow or pressure instruments simultaneously
- Power output: -15 VDC at 450 mA and +15 VDC at 150 mA
- Input voltage: 100-125 VAC / 200-250 VAC, 50/60 Hz - dual-range compatible
- 4-20 mA analog signal compatibility
- Four rear-panel 15-pin D-sub connectors, one per channel (Channels 1-4 labeled)
- Terminal block strip for external command inputs on rear panel
- F1 0.5A fuse holder on rear panel
- Active LCD display - confirmed operational, showing live readings in photos
- OPEN/AUTO/CLOSED switches per channel - all confirmed intact
- Half-rack panel mountable; desktop stand attached and intact
- Chrome carry handle with secure pivot mounts - portable bench use
Applications
- Powering and reading Teledyne Hastings mass flow meters and mass flow controllers in lab or process environments
- Vacuum gauge and pressure transducer power supply for research instrumentation setups
- Secondary calibration reference stations requiring multi-instrument simultaneous operation
- Gas blending, thin film deposition, and gas generation process support
- Pharmaceutical production and fuel cell testing instrument support
- Portable or temporary multi-channel flow measurement setups
Frequently Asked Questions
Which instruments is this compatible with?
Designed for Teledyne Hastings mass flow meters, mass flow controllers, vacuum gauges, and pressure transducers that use 15-pin D-sub connectors and 4-20 mA analog signals. Verify the connector type and power requirements of your specific Teledyne Hastings instruments before connecting. Compatibility with non-Teledyne instruments is not confirmed.
Was this tested beyond powering on?
Confirmed to power on. The display is active, all knobs and switches are responsive. Full functional testing with connected mass flow controllers or meters was not performed. Verify functional status with your instruments before deploying in a critical process.
What is included with this unit?
The Model 400 unit with desktop stand and attached power cord. No instrument cables, documentation, or accessories are included.
Is RS-232 or RS-485 communication available on this unit?
Not confirmed for this specific Model 400 serial number. Communication interfaces including RS-232 and RS-485 are documented for the later THPS-400 variant. Verify against the rear panel and any available documentation for this exact unit before assuming serial communication is present.
Can cables longer than 25 feet be used with this power supply?
Cable length beyond 25 feet may affect calibration for connected flowmeters and could require recalibration. Verify cable length requirements against your instrument specifications before use.
The rear label says Hampton, VA - Teledyne Hastings has been building flow instrumentation there for decades, and this unit carries that lineage. Four channels, a working display, and a power cord already attached: someone's bench just got a little more capable.
