Meltric 17-18081 DN9c Pin and Sleeve Male Inlet Plug Connector, 20A 480VAC/130VDC, 8-Pin + Ground
Product Condition
New, in manufacturer’s packaging. Box opened only for inspection and photos. Will be securely repackaged for safe shipping. One inlet connector included.
Product Overview
The Meltric 17-18081 is an industrial-grade, multipin inlet from the DN9c series. Rated for 20 A, 480 VAC/130 VDC, and capable of handling up to 5 HP, this inlet features an 8-pin plus ground configuration. Built-in switch-rated contacts and a rugged metal housing ensure safe, reliable performance in demanding industrial environments.
Key Features
- Brand: Meltric
- Part Number: 17-18081
- Series: DN9c
- Rated Current: 20 Amp
- Rated Voltage: 480 VAC / 130 VDC
- Horsepower Capacity: up to 5 HP (at 480 VAC, 3-phase)
- Contact Configuration: 8 Pin + Ground (9 wires)
- Environmental Rating: IP54/IP55 (dust and splash resistant)
- Operating Temperature Range: –40 °F to 140 °F (–40 °C to 60 °C)
- Construction: Metal housing with screw-terminal connections
- Switch-rated, spring-loaded silver-nickel butt-style contacts
Applications
- Industrial power distribution and maintenance
- Automation and control systems
- Manufacturing machinery and heavy-duty equipment
- Situations requiring safe, load-making/breaking electrical connections
Frequently Asked Questions
Who is Obtainium Science and Surplus?
We're a lean crew that finds real scientific and industrial gear. Parts with history. Tools that still work. Customers are engineers, makers, labs, and shops that build for a living.
How fast is shipping?
Same day or next day on most orders. Email confirmation and tracking. Secure packaging.
What’s included?
One Meltric 17-18081 DN9c inlet connector. No accessories, manuals, or wires included.
