Raco RLB200 2 Inch LB Conduit Body with Cover, Die-Cast Aluminum, Unused

Raco Incorporated

$20.96
SKU:
000093023030MM23Store
Condition:
New
Availability:
Usually ships same or next business day.
Adding to cart… The item has been added

Product Overview

Type LB Die-Cast Aluminum Conduit Body for 2 Inch Rigid and IMC, Stamped Cover

Condition

Unused new old stock, stored unboxed, with minor scuffs and scratches from handling. The stamped aluminum cover, its NBR synthetic rubber gasket and its two screws are included, with the cover installed. Markings legible: UL mark, LB and 2 on the body; 2" COVER and the cULus listing mark on the cover.

Ready to ship from our Idaho warehouse the same or next business day. Selling online since 1999.

Product Overview

Raco's RLB200 is a Type LB conduit body for 2 inch rigid and IMC conduit, die-cast aluminum with a powder coat finish. The LB pattern puts the access opening on the back, so a run can turn 90 degrees through a wall or ceiling while the conductors stay reachable for pulling and splicing.

Key Features

  • Type LB pattern: access opening on the back of the body
  • 2 inch threaded hubs at both ends, for rigid and IMC conduit
  • Die-cast aluminum body, gray powder coat finish
  • Stamped aluminum cover, marked 2" COVER, held by two screws
  • NBR synthetic rubber cover gasket
  • Body 10.05 x 3.19 x 4.51 in (L x W x H)
  • UL mark on the body, cULus listing mark on the cover

Applications

  • Turning an exposed 2 inch run 90 degrees through a wall, ceiling or panel
  • Adding a pull point on a long run so conductors do not have to be fed through every bend
  • Giving splice access at a corner in commercial and industrial wiring

Frequently Asked Questions

Is this an LB or an LR body?

LB. The body is marked LB and the opening faces the back. An LR has its opening on the side.

What conduit does it fit?

2 inch threaded rigid or IMC conduit, one run into each hub.

Is the cover the right size for the body?

Yes. The cover is stamped 2" COVER and is mounted on the body with its two screws. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

An LB is the conduit world's elbow with a back door. Run the pipe to the wall, let this body make the turn, and pull the wire through where you can reach it.
