Cased Eddy Current Flaw Detection Instrument for NDT, Powers Up, Sold for Parts or Repair
Condition
Used, fair cosmetic condition with scratches, scuffs, dents and chipped paint on the case. Tested to power up only; no further function testing. Sold strictly as-is, for parts or repair, and no manuals, instructions or additional accessories are included. Markings legible: nameplate Model MIZ-30-4, Serial No. 024; panel plate MIZ-30-2; calibration label SER 024, DATE 25 OCT 95, EXP 25 APR 96; AC POWER 90-260 VAC 50-60 HZ; FUSES 2A.
Ships same or next business day from our Idaho warehouse. Selling online since 1999.
Product Overview
Eddy current instruments drive a probe with alternating current and read the change in its response to find flaws in conductive metal. This MIZ-30 series unit is built into a blue carrying case with a handle and latches, its panel carrying the connectors, fuses and power inlet.
Key Features
- Nameplate Model MIZ-30-4, panel plate MIZ-30-2
- AUXILIARY connector and LAN IEEE 802.3 port
- DIFFERENTIAL IEEE 488 circular connector
- Capped ports marked BOARDS 1 & 2 and SPARE
- AC POWER inlet marked 90-260 VAC 50-60 HZ
- Two panel fuses marked 2A and a POWER ON lamp
- Blue carrying case with top handle and latches
Applications
- A parts source for a technician keeping another MIZ-30 series instrument running
- A repair project for an NDT shop with its own probes
- Teardown and repair practice for eddy current technicians
Frequently Asked Questions
Does it power up?
Yes. It was tested to power up only, with no further function testing.
Why does the panel read MIZ-30-2 when the nameplate reads MIZ-30-4?
Both plates are on the unit. The nameplate reads Model MIZ-30-4, Serial No. 024, and a separate black plate on the panel reads MIZ-30-2.
Are manuals or probes included?
Not included.
Is it sold as-is for parts or repair?
Yes. It powers up and has had no further function testing, and the case shows scratches, scuffs, dents and chipped paint. You get the instrument as shown and take on diagnosis and repair. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
The calibration label on the panel came due on 25 APR 96. What it measures after that date is up to the bench that takes it on.
