Sensitive Research Instruments 902246 Current Shunt 7.5 A 100 mV Used

Sensitive Research Instruments

$123.99
SKU:
000031123014J23Store
Condition:
Used
Availability:
Usually ships same or next business day.
Adding to cart… The item has been added

Product Overview

Vintage 7.5 Ampere / 100 Millivolt Current Shunt, Accuracy .1 of 1%

Condition

Used, in good clean condition, a nice vintage unit. Visual inspection only. Function testing not performed. Markings legible: SENSITIVE RESEARCH with the diamond S logo, 7.5 AMPERES, Nº 902246, ACCURACY .1 OF 1%, 100 MILLIVOLTS, FOR USE WITH INSTRUMENT Nº 902240, and a handwritten L6606 on the base.

Ships from our Idaho warehouse the same or next business day. We've been selling online since 1999.

Product Overview

A current shunt turns a current into a small voltage a meter can read, and at its rated 7.5 amperes this one develops 100 millivolts. It carries Nº 902246 and is for use with instrument Nº 902240. A flat bar runs between two square blocks on a black base, with a standoff post at each corner.

Key Features

  • Rating: 7.5 amperes, 100 millivolts
  • Accuracy: .1 of 1%
  • For use with instrument Nº 902240
  • Two square blocks joined by a flat bar, each with a hex-head bolt and washer on top and a slotted screw on the side
  • Black base with a hexagonal standoff post at each of its four corners
  • Underside plate held by four slotted corner screws

Applications

  • Pairing with instrument Nº 902240
  • Reading currents up to 7.5 amperes on a meter scaled for a 100 millivolt shunt
  • A period piece for a collection of vintage electrical measuring gear

Frequently Asked Questions

Which instrument is it for use with?

Instrument Nº 902240. The shunt itself carries Nº 902246.

What voltage does it develop at full rating?

100 millivolts at 7.5 amperes.

Has it been tested against its accuracy rating?

No. It is used, in good clean condition, a nice vintage unit, and it has had a visual inspection only, with no function testing. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

Nº 902246 is the shunt and Nº 902240 is the instrument it is for use with. Six digits apiece, and only the final digit differs.
