Festo LFR-D-MINI Filter Regulator Stack, HE-D-MINI, HEE-D-MINI-24, Used

Festo

$144.00
SKU:
000051725001s25Store
Condition:
Used
Availability:
Usually ships same or next business day.
Quick Details:
Compact FESTO pneumatic regulator/valve assembly with solenoid and manual controls.
Adding to cart… The item has been added

Product Overview

Three-Station Compressed Air Prep Stack: Filter Regulator with Gauge, Manual and 24 V Shut-Off Valves

Condition

Used, clean, and in excellent cosmetic condition. Visual inspection only. Function testing not performed. Components show light handling but no damage. The LFR-D-MINI filter element is not included; the pneumatic fittings and mounting brackets are included. Markings legible: HE-D-MINI, p1 max 16 bar, 230 psi, 1,6 MPa, 185733, W443; HEE-D-MINI-24, p1 min 2,5 bar, p1max 16 bar, 172956, W443; bowl label Polycarbonate bowl, max. 16bar/230 psi/1,6 MPa, max. 60 C/140 F, TUV SUD Type Tested.

Selling online since 1999. This one ships from our Idaho warehouse the same or next business day.

Product Overview

Festo's D-series MINI units bolt together into one air preparation line, and this stack carries three of them. A HE-D-MINI valve with a blue knob sits at the inlet, the LFR-D-MINI filter regulator with its gauge and polycarbonate bowl sits in the middle, and a HEE-D-MINI-24 shut-off valve with a wired solenoid sits at the outlet.

Key Features

  • LFR-D-MINI filter regulator with center-mounted gauge, 0 to 16 scale
  • HE-D-MINI manual on/off valve, p1 max 16 bar, 230 psi, 1,6 MPa
  • HEE-D-MINI-24 electrically actuated shut-off valve, Festo 172956, 24 V
  • HEE-D-MINI-24 label: p1 min 2,5 bar, 36 psi, 0,25 MPa
  • MSEB-3-24V DC solenoid coil, 24 V DC plug-in type
  • Polycarbonate bowl rated max. 16 bar and 60 C, 140 F
  • Mounting brackets, push-in elbow and quick-coupler plug fitted

Applications

  • Replacing a worn Festo MINI air prep stack on a machine without re-plumbing the panel
  • Adding regulated, switchable air to a test fixture where a 24 V output turns the supply on and off
  • Keeping a matched spare for an automation line built on Festo D-series units

Frequently Asked Questions

What pressure is it rated for?

16 bar, 230 psi or 1,6 MPa at the inlet, printed on the valve labels and the bowl. The bowl adds a 60 C, 140 F limit.

Does the electric valve need a minimum pressure?

Yes. The HEE-D-MINI-24 label reads p1 min 2,5 bar, which is 36 psi or 0,25 MPa.

Is the filter element included?

Not included.

Will it match the HEE-D-MINI-24 on an existing Festo stack?

Yes, if your old valve reads HEE-D-MINI-24. This one carries that type and the number 172956 on its label, the same pair to match on yours. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

Each label carries its own pressure limit, and the bowl adds a temperature one: 60 C, 140 F. Check your line against those numbers before the first bar goes in.
