Square D BGL36060 PowerPact B Circuit Breaker 3P 60A 480V 35kA, Unused

Square D

$792.99
SKU:
000061723002X23LS
Condition:
New
Availability:
Usually ships same or next business day.
Adding to cart… The item has been added

Product Overview

PowerPact B-Frame 3-Pole 60 Amp Thermal-Magnetic Molded Case Circuit Breaker, 35kA at 480 VAC

Condition

Unused new old stock. The box has been opened but appears complete, and it comes with a small hardware bag and a printed sheet. Markings legible: BG60, BGL36060, Circuit Breaker, Interruptor Automático, Disjoncteur, Interrupting Rating 240~ 65kA, 480~ 35kA, 600Y/347~ 18kA, 250 DC 20kA, 40°C, 50/60Hz, 75°C wire only, UL Listed CB E63335 Issue No. 186, CSA 177007, NOM, HACR S1, 60A, LV426974, In ≤ 100 A: CU/AL, In > 100 A: CU ONLY, #14 - #8 CU/AL 44 lb-in, #6 - #3/0 CU/AL 80 lb-in, Approved for use with fine stranded class K #6 - #2/0 CU ONLY 80 lb-in, IEC/EN 60947-2, Ui 800V, Uimp 8kV, Cat. A, PowerPact, MFR17397, BGL36060-G2, SQUARE D by Schneider Electric; on the box: PowerPact B, 3P 60A 35kA @ 480V~, Assembled in MX with MX & Foreign Parts, 7319335, CE, CCC, UL, CSA, NOM, barcode 3 606481 154118. Light scratch marks cross the IEC rating table on the face.

Ships from our Idaho warehouse the same or next business day. We've been selling online since 1999.

Product Overview

A PowerPact B-frame molded case circuit breaker from Square D by Schneider Electric: three poles, 60 amps, a thermal-magnetic trip and lug connections. Its interrupting rating steps from 65kA at 240 VAC to 35kA at 480 VAC and 18kA at 600Y/347 VAC, with 20kA at 250 VDC.

Key Features

  • Three poles, 60 amp rating, thermal-magnetic trip
  • Interrupting rating: 65kA at 240 VAC, 35kA at 480 VAC, 18kA at 600Y/347 VAC, 20kA at 250 VDC
  • 80% rated; HACR S1
  • Lugs take #14 to #8 AWG copper or aluminum at 44 lb-in and #6 to #3/0 AWG copper or aluminum at 80 lb-in
  • Fine stranded class K wire, #6 to #2/0 AWG, copper only, at 80 lb-in
  • 75°C wire only; 50/60 Hz; 40°C
  • IEC/EN 60947-2: Ui 800V, Uimp 8kV, Category A
  • UL Listed, CSA, NOM, CE and CCC

Frequently Asked Questions

Can I land aluminum wire on it?

Yes. The lugs take copper or aluminum from #14 to #3/0 AWG. Fine stranded class K wire, #6 to #2/0, is copper only.

Does it carry a DC rating?

Yes. 20kA at 250 VDC.

Is it rated for 480 volt service?

Yes. Its interrupting rating is 35kA at 480 VAC and 18kA at 600Y/347 VAC. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.

Sixty amps in its own little window and the handle parked at OFF. Where it goes from here is up to your one-line drawing.
