Product Overview
Infinity-Corrected 50x Long Working Distance Objective for an f=200 Tube Lens
Condition
Used, with clean optics of very good glass quality and some exterior blemishes from prior handling. Visual inspection only. Function testing not performed. Comes with a 1X adapter ring and breadboard mounting hardware: an L bracket and two shoulder screws; markings legible: M Plan Apo, 50x / 0.55, ∞ / 0 and f = 200 on the barrel, and 1X ADAPTER, Mitutoyo and MADE IN JAPAN on the black adapter ring.
Ships same or next business day from our Idaho warehouse. Selling online since 1999.
Product Overview
A 50x plan apochromat from the Mitutoyo M Plan Apo line of long working distance objectives for infinity-corrected inspection microscopes. At 0.55 NA it holds 13 mm of clearance between the front lens and the work, room for probes, fixtures and tall parts.
Key Features
- Magnification and numerical aperture: 50x / 0.55
- Infinity corrected (∞ / 0) for an f=200 mm tube lens
- Working distance 13 mm; focal length 4 mm
- Parfocal length 95 mm
- Bright field observation, corrected from 436 to 656 nm
- Resolving power 0.5 µm; depth of focus 0.9 µm
- Black 1X ADAPTER ring with a knurled grip at the mount end
- L bracket with a threaded through-hole and two slots in its base
Applications
- Swapping a 50x into an infinity-corrected inspection setup built around an f=200 tube lens
- Inspecting wafers, die and fine circuit features where 13 mm of clearance keeps probes and fixtures out of the way
- Building a microscope or machine vision path on an optical breadboard with the bracket and screws
- Holding a spare objective for a metrology or failure analysis bench
Frequently Asked Questions
What tube lens does it work with?
An f=200 mm tube lens. It is infinity corrected.
How much working distance does it give?
13 mm, with a 4 mm focal length and a 95 mm parfocal length.
Has it been tested on a microscope?
No. Visual inspection only; function testing not performed. The optics are clean with very good glass quality, and the exterior shows some blemishes from prior handling. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
Fifty times at 0.55 NA, for an f=200 tube lens. The blemishes are on the outside, and the glass is clean.
