National Instruments SHC68-68-EP 68-Pin Cable – Used DAQ Interconnect
Presented here is a National Instruments SHC68-68-EP cable designed to connect NI Multifunction I/O devices and modules using a 68-pin SCSI 0.050 D-Type connector.
In data acquisition systems, the cable is not an accessory - it is part of the signal path. NI designed the SHC68-68-EP to maintain clean, consistent connections between hardware components where pin integrity and connector fit matter as much as the measurement device itself.
Product Condition
This cable is used and appears in good physical condition based on visual inspection. No electrical testing was performed. Only the cable shown is included.
Product Overview
National Instruments is widely known for modular data acquisition and control platforms used in test, research, and industrial environments. The SHC68-68-EP cable is intended for use with NI Multifunction I/O devices and modules equipped with the SCSI 0.050 D-Type 68-pin connector. Length is about 19.5" long.
It serves as a system interconnect, linking DAQ hardware to compatible termination blocks or modules while preserving proper pin mapping.
Key Features
- National Instruments SHC68-68-EP cable
- 68-pin SCSI 0.050 D-Type connectors
- Designed for NI Multifunction I/O devices and modules
- DAQ system interconnect cable
- Maintains correct pin-to-pin signal routing
- Used in test and measurement environments
- Manufactured by National Instruments
Applications
- NI data acquisition system integration
- Connecting DAQ devices to terminal blocks
- Laboratory test and measurement setups
- R&D instrumentation systems
- Industrial monitoring and control systems
- Legacy NI hardware maintenance
Frequently Asked Questions
What devices is this cable compatible with?
This cable is intended for National Instruments Multifunction I/O devices and modules that use a 68-pin SCSI 0.050 D-Type connector.
Is this a SCSI data cable?
While it uses a SCSI-style connector, this cable is designed for DAQ signal routing, not for computer SCSI data communication.
Has the cable been electrically tested?
No continuity or signal testing was performed. Condition is based on visual inspection.
Are both ends the same connector?
Yes, this model uses 68-pin connectors on both ends.
Does it include any additional hardware?
No additional accessories are included beyond the cable shown.
Every measurement chain depends on its quietest component. This SHC68-68-EP is ready to take its place back in the system.
