Product Overview
1/2 Inch Code 62 Split Flange Halves, Bolts, Washers and O-Ring for -8 Four-Bolt Ports
Condition
Unused new old stock in the original manufacturer packaging, opened to photograph the contents. Contents: two bright zinc-finished clamp halves, four black hex head bolts, four split lock washers and one O-ring. Marking legible on each clamp half: -8. The unit pictured is representative of stock.
Ships same or next business day from our Idaho warehouse. Selling online since 1999.
Product Overview
Weatherhead built the SFK62-8 for 1/2 inch Code 62 ports. Each half is cast with the -8 size mark, so the halves are easy to match to their port in a parts drawer. Code 62 is the higher-pressure series of the SAE J518 four-bolt flange; at 1/2 inch it shares its bolt thread with Code 61, so the bolt spacing is what separates them.
Key Features
- 1/2 inch (-8) SAE Code 62 hydraulic split flange kit, carbon steel
- Two clamp halves, bright zinc finish, each cast -8
- Four black hex head bolts
- Four split lock washers
- A single O-ring for the flange face
Applications
- Mounting a 1/2 inch Code 62 flange head fitting on a pump, valve or manifold port
- Replacing lost or damaged clamp hardware during a hose change
- Keeping a matched small-port kit on hand for a machine with 1/2 inch Code 62 ports
Frequently Asked Questions
Will a 1/2 inch Code 62 kit fit a Code 61 port?
No. A 1/2 inch Code 62 port spaces its bolts 1-19/32 inch across the long side of the pattern; a Code 61 port of the same size measures 1-1/2 inch. Both codes take 5/16-18 bolts at this size, so check the spacing, not the thread.
Is a flange head fitting part of the kit?
Not included. These halves hold a 1/2 inch flange head fitting or adapter against the port; the fitting is a separate purchase.
How can I check the size of the halves I already have?
Look for a cast dash number. These halves are marked -8, the 1/2 inch size. Flat-rate shipping in the lower 48, and orders over the free-shipping line ship free.
The -8 cast into each half is the most useful number in a drawer full of flange hardware. Read the mark on your old halves, and this kit answers it.
